Hands-on Workshop on PCB Layout Design

Events Details

  • DATE :   Saturday, October 8, 2016
  • TIME :   9:00 AM to 04:00 PM
  • DAY :   Saturday
  • VENUE :   MA112 & MA115, MEFGI

Ever wondered how all the magic works behind the scenes of electronics? How do the resistors capacitors, transistors so on so forth work in particular configurations as theorized and drawn on paper? Well it's usually seen on what they call a Printed Circuit Board (PCB).

We often come across two scenarios where we need PCB designing. Sometimes we need to fix a medium/large sized circuit with various components into a smaller and more compact form. And sometimes we need to use a specific circuit more number of times. In such cases, making a Printed Circuit Board of the required circuit is very useful.

Club is actively teaching and conducting events like workshop, seminars and industrial visits in the area of PCB Layout Design and fabrication.

Content delivered in the workshop

·         Difference between general purpose and special purpose PCB

·         Single layer and multi-layer PCB design

·         Steps for PCB design (Schematic, PCB Layout, Etching, drilling etc...)

·         Live demonstration of each process

Identification of different surface mounted components on any complex PBC
